R210W-9S
Hyundai
| Availability: | |
|---|---|
|
|
![]() | ![]() |
Advantages
Powerful power and drive: The Hyundai R210W-9S excavator is equipped with a high-performance engine and a powerful hydraulic system, which can provide sufficient power and drive for various excavation and bulldozing work.
Flexibility and maneuverability: The compact design and excellent handling performance of this excavator enable it to fit into small working spaces and operate flexibly in narrow or crowded places.
Efficient working ability: The Hyundai R210W-9S excavator has excellent digging and loading capabilities, which can quickly complete various tasks and greatly improve work efficiency.
Brand-new hydraulic system: This excavator adopts the latest hydraulic system technology, which can achieve more precise and smooth operation and improve the overall work quality.
Comfortable cab: The Hyundai R210W-9S excavator cab is spacious and comfortable, equipped with an advanced air conditioning system and a suspended seat, providing the operator with a good working environment and comfort.
Reliable and durable design: The excavator features a structurally solid design and durable materials, which improves overall reliability and durability, and reduces the risk of repairs and breakdowns.
Easy to maintain and service: The individual components and parts of the R210W-9S excavator are carefully designed for easy maintenance and service, reducing repair time and expense.
|
|
![]() | ![]() |
Advantages
Powerful power and drive: The Hyundai R210W-9S excavator is equipped with a high-performance engine and a powerful hydraulic system, which can provide sufficient power and drive for various excavation and bulldozing work.
Flexibility and maneuverability: The compact design and excellent handling performance of this excavator enable it to fit into small working spaces and operate flexibly in narrow or crowded places.
Efficient working ability: The Hyundai R210W-9S excavator has excellent digging and loading capabilities, which can quickly complete various tasks and greatly improve work efficiency.
Brand-new hydraulic system: This excavator adopts the latest hydraulic system technology, which can achieve more precise and smooth operation and improve the overall work quality.
Comfortable cab: The Hyundai R210W-9S excavator cab is spacious and comfortable, equipped with an advanced air conditioning system and a suspended seat, providing the operator with a good working environment and comfort.
Reliable and durable design: The excavator features a structurally solid design and durable materials, which improves overall reliability and durability, and reduces the risk of repairs and breakdowns.
Easy to maintain and service: The individual components and parts of the R210W-9S excavator are carefully designed for easy maintenance and service, reducing repair time and expense.
General
| Operating Weight | 20.5 ton |
Bucket Capacity | 0.8 m³ |
Engine
| Emission | TIER 2 |
| Engine model | HYUNDAI HM5.9 |
| Rated Power | 178hp/2000rpm |
| Max. Torque | 72.2kgf·m/1500rpm |
Hydraulic
| Main pumps rated flow | 2×192 ℓ/min |
| Implement circuit | 350 kgf/cm2 |
Tank Capacity
| Fuel tank | 310 ℓ |
| Hydraulic tank | 165 ℓ |
OIL CAPACITY
| Fuel Tank | 120L |
| Hydraulic Oil Tank | 70L |
Performance
| Swing speed | 10.5 rpm |
| Travel speed | 30 km/h |
| Max. Traction force | 11900 kgf |
| Max. gradeability | 34 deg |
| Bucket Digging Force (ISO) | 16830 kgf |
| Arm Digging Force (ISO) | 11830 kgf |
Working Range
| Boom length | 5650 mm |
| Arm length | 2920 mm |
| Max. Digging reach | 9960 mm |
| Max.Digging depth | 6380 mm |
| Max. Digging Height | 10000 mm |
| Max. Dumping Height | 7160 mm |
| Min. Swing radius | 3580 mm |
General
| Operating Weight | 20.5 ton |
Bucket Capacity | 0.8 m³ |
Engine
| Emission | TIER 2 |
| Engine model | HYUNDAI HM5.9 |
| Rated Power | 178hp/2000rpm |
| Max. Torque | 72.2kgf·m/1500rpm |
Hydraulic
| Main pumps rated flow | 2×192 ℓ/min |
| Implement circuit | 350 kgf/cm2 |
Tank Capacity
| Fuel tank | 310 ℓ |
| Hydraulic tank | 165 ℓ |
OIL CAPACITY
| Fuel Tank | 120L |
| Hydraulic Oil Tank | 70L |
Performance
| Swing speed | 10.5 rpm |
| Travel speed | 30 km/h |
| Max. Traction force | 11900 kgf |
| Max. gradeability | 34 deg |
| Bucket Digging Force (ISO) | 16830 kgf |
| Arm Digging Force (ISO) | 11830 kgf |
Working Range
| Boom length | 5650 mm |
| Arm length | 2920 mm |
| Max. Digging reach | 9960 mm |
| Max.Digging depth | 6380 mm |
| Max. Digging Height | 10000 mm |
| Max. Dumping Height | 7160 mm |
| Min. Swing radius | 3580 mm |
