330D2
CAT
| Availability: | |
|---|---|
|
|
![]() | ![]() |
Advantages
1. Powerful performance for efficient operation.
2. Excellent durability ensures long service life.
3. Cost-effective choice compared to new ones.
4. Proven reliability in various construction tasks.
|
|
![]() | ![]() |
Advantages
1. Powerful performance for efficient operation.
2. Excellent durability ensures long service life.
3. Cost-effective choice compared to new ones.
4. Proven reliability in various construction tasks.
ENGINE
| Engine Power - ISO14396 | 159.0 kW |
| Net Power - ISO 9249 (DIN) | 156.0 kW |
| Engine Model | Cat® C7.1 ACERT™ |
WEIGHTS
| Working weight | 28955.0 kg-30115.0 kg |
| Standard chassis system | Extended type: 6630.0kg. |
HYDRAULIC SYSTEM
| Rotary system–the maximum flow | 240.0 L/min |
| Pilot system-maximum flow rate | 23.1 L/min |
| Pilot system-max. pressure | 3920.0 kPa |
| Main system–the maximum flow | 247 × 2 L/min |
DRIVE
| Maximum driving speed | 5.3 km/h |
| Maximum traction | 248.0 KN |
MAINTENANCE FILLING CAPACITY
| fuel capacity | 520.0 L |
cooling system | 31.0 L |
| Engine oil | 22.0 L |
| Hydraulic tank oil | 257.0 L |
ENGINE
| Engine Power - ISO14396 | 159.0 kW |
| Net Power - ISO 9249 (DIN) | 156.0 kW |
| Engine Model | Cat® C7.1 ACERT™ |
WEIGHTS
| Working weight | 28955.0 kg-30115.0 kg |
| Standard chassis system | Extended type: 6630.0kg. |
HYDRAULIC SYSTEM
| Rotary system–the maximum flow | 240.0 L/min |
| Pilot system-maximum flow rate | 23.1 L/min |
| Pilot system-max. pressure | 3920.0 kPa |
| Main system–the maximum flow | 247 × 2 L/min |
DRIVE
| Maximum driving speed | 5.3 km/h |
| Maximum traction | 248.0 KN |
MAINTENANCE FILLING CAPACITY
| fuel capacity | 520.0 L |
cooling system | 31.0 L |
| Engine oil | 22.0 L |
| Hydraulic tank oil | 257.0 L |
